Place

Iringa - Tanzania


Client

Zarubezhstroy Ojsc (Beneficiary: Tanzania, Ministry of Energy and Minerals)


Year

2011 - in progress

Description for Rumakali Hydropower (Tanzania)

Hydroelectric Power Plant, with IP = 525 MW, which the exploits of N° 5 catchment areas, providing a total of Q = 23 m³/s and a geodetic head of 1,423 m.

Main Features

  • Rumakali Dam ( Rockfill dam, H = 93 m, L = 800 m )
  • North Site main Dam ( Rockfill dam, H=71 m )
  • East Site main Dam ( Rockfill dam, H= 140 m )
  • Free-Flow Spillway ( Rumakali dam, Q = 350 m³/s )
  • Power Waterways ( Rumakali Head Race Canal L = 4.5 km, West Site Canal L = 3.8 km, East Site Pipe Line HP L= 2,4 km )
  • Open Air Pumping Station ( Q = 19.5 m³/s )
  • Power House ( Underground, 90 x 23 x 44 m, Head = 1,423 m, Q = 41 m³/s, N°4 Turbines Pelton )
  • Transmission line ( V = 220 kV, L = 94 km )


Engineering Services

  • Conceptual Scheme
  • Feasiblity Design
  • BOT Contract documents
  • ESIA
